Vermeer Equipment Broyeurs Lents Broyeur lent LS3600

Broyeur lent LS3600

• Accès complet au rotor, au peigne et au convoyeur ventral grâce à une porte latérale hydraulique

• Télécommande multifonction permettant de régler la machine, de consulter ses données et de diagnostiquer les codes de défaut à distance

• Transmission mécanique réversible avec limiteur de couple pour optimiser la puissance et protéger les composants essentiels

• Dents de peigne individuelles à double extrémité pour prolonger leur durée de vie et réduire les coûts d’usure

• Compartiment moteur largement accessible pour faciliter les opérations d’entretien et de maintenance

• Convoyeur ventral amovible sans démontage du convoyeur de décharge

Base Image
Small Image
Small Image
Small Image
Small Image
Base Image
Small Image
Small Image
Small Image
Small Image
Demander un Devis Télécharger la brochure vermeer icon

Les broyeurs lents Vermeer apportent plus de flexibilité en recyclage, surtout sur les déchets contaminés. La basse vitesse privilégie le couple et garde un bon niveau de contrôle sur le traitement.

L’entretien reste accessible et rapide. Vous limitez les arrêts et vous restez opérationnel plus longtemps. Contactez Vermeer France pour choisir le modèle et demander un devis.

Le broyeur lent LS3600 Vermeer traite efficacement les déchets volumineux grâce à son moteur Stage V de 340 kW, son rotor de 3,1 m et sa trémie de 7,8 m³. Sa conception facilite également l’utilisation et l’entretien.

Général

Fabricant Vermeer
Modèle Broyeur lent LS3600
Catégorie Recyclage
Prix Demander un devis

General Dimensions and Lengths

Maximum Length - Transport 33.5ft (10.2m)
Maximum length - working 52.6ft (16m)
Maximum Width (Transport) 8.2ft (2.5m)
Maximum Height (Transport) 11.6ft (3.5m)
Maximum weight 72752lbs (32999.8kg)
Maximum tongue weight 19841lbs (8999.7kg)
Maximum axle group weight 52910lbs (23999.6kg)
Make and Model CAT C13B T4F/STAGE V
Number of Cylinders 6
Gross Horsepower (Maximum) 456hp (340kw)
Torque (Maximum) 2082ft-lb (2822.8Nm)
Fuel Tank Capacity 146gal (552.7L)
Max Fuel Consumption 19.3gph (73.1lph)
Fuel Type Ultra-low sulfur diesel (<15 ppm)
Diesel exhaust fluid capacity 17.3gal (65.5L)
Air Cleaner Dry-type w/ primary & secondary elements and restriction indicator
Oil Filter Full-flow, spin-on
Recommended Oil API CJ-4, 15W-40
Oil Volume with Filter 45qt (42.6L)
Cooling Medium Liquid (nitrite free pre-diluted 50/50)
Coolant Capacity (Engine and Radiator) 13.7gal (51.9L)
Air to boil temperature 134 F (56 C)
Alternator 24 V 150 A
Fan Multi-wing (variable pitch)
Fan - CAC Electric (variable speed)
Transmission Type Reversing dual clutch
Planetary type Gearbox
Torque Limiter Ball detent
Driveline brake type Single caliper disk
Sound Power 108.2 dB(A)
Infeed hopper width 86in (218.4cm)
Infeed hopper depth 44in (111.8cm)
Infeed hopper length 147.8in (375.3cm)
Infeed hopper capacity 10.2cu yd (7.8cu m)
Loading Height 10.6ft (3.2m)
Hopper extension construction Integrated steel with hyd. cyl.
Hopper extension height 18in (45.7cm)
Hopper extension depth 3in (7.6cm)
Hopper extension length 67in (170.2cm)
Hopper extension loading height 11.3ft (3.4m)
Feed opening 88-in (225-cm) wide x 145.75-in (3.7-m) long
Rotor weight 5700lbs (2585.5kg)
Rotor diameter 24.5in (62.2cm)
Tip Diameter 39.5in (100.3cm)
Short tip diameter 36.8in (93.3cm)
Rotor length 122ft (37.2m)
Rotor skin thickness 1.3in (3.2cm)
Rotor Speed 30rpm
Tip speed 310ft/min
Number of mounts 21
Number of Tips 21
Tip types Tall/short
Wear Plate Thickness .5in (1.3cm)
Length 16ft (4.9m)
Width 41in (104.1cm)
Belt Design 1-ply - 330# with V-cleat - Steel mesh
Splice Continuous
Tail pulley diameter 9in (22.9cm)
Drive pulley diameter 9in (22.9cm)
Drive Motor Fixed displacement
Belt Speed 784ft/min (239m/min)
Length 22.3ft (6.8m)
Width 48in (121.9cm)
Belt Design 3-ply - 330# with V-cleat
Splice R2 stainless steel cable
Return Roller Quantity 2
Tail pulley diameter 12in (30.5cm)
Drive pulley diameter 12.8in (32.4cm)
Drive Motor Fixed displacement
Belt Speed 824ft/min (251.2m/min)
Load Height 8 ft - 14 ft (2.43 m - 4.3 m)
Tank capacity 40gal (151.4L)
Recommended Oil Vermeer HyPower 68
Filtration Method Dual in-tank return filters
Number of Coolers 1
Components 11 section
System Type Open-loop
Pump Type 23/8 CC Tandem
Pump Flow at Maximum RPM 12.7 gpm (61.9 L/min) / 4.4 gpm (16.6 L/min)
System relief pressure 2900psi (199.9bar)
System Type Closed-loop
Pump Type Variable piston
Pump Flow at Maximum RPM 32.5gpm (123L/min)
System Pressure 3336psi (230bar)
Motor type Orbital
System Type Closed-loop
Pump Type Variable piston
Pump Flow at Maximum RPM 32.5gpm (123L/min)
System Pressure 3336psi (230bar)
Motor type Orbital
System Type Closed-loop
Pump Type Variable piston
Pump Flow at Maximum RPM 16.3gpm (61.7L/min)
System relief pressure 3626psi (250bar)
Motor type Series 40 - Axial Piston
Fan type (FWD/REV) Multi-wing (variable pitch)
System Voltage 24 Volt
Battery 8D-MHD, 1400 CCA (qty.2)
System Protection Fused
Display Type LCD touchscreen
Engine Information Yes
Machine Information Yes
Operational Faults Yes
Gauges No
Switches Sealed membrane CANbus keypad
Display Type LCD
Engine Information Yes
Machine Information Yes
Operational Faults Yes
Gauges No
Switches Sealed membrane
Operating Range 300 ft (91.4 m)
Battery Type AA (qty. 6)
Channel Setting 50 channels
Frame Description Unit body construction
Tongue Description Fabricated
Hitch Type EU 5th wheel with creep drive
Fender Description Plastic, replaceable
Brake Type EU EBS
Trailer Light Type 12-24V LED
Suspension Type Spring
Manufacturer - Option One Hutchens Industrial, Inc.
Capacity per Axle 17636lbs (7999.6kg)
Number of axles (5th wheel) 3
Tires - Option One 385/65R22.5
Wheels - Option One Aluminum
Ground Clearance 9.3in (23.6cm)
Tips Yes
Overband magnet Optional
Dust suppression Optional
Foldable rear hopper extension Optional
Extended Warranty Optional
Preventative Maintenance Optional
Special Paint Optional
Vermeer Confidence Plus Asset Protection Program Optional

Literature

Fiche technique Broyeur lent LS3600 - Anglais Download
